MP5046 is a single-chip IC specially designed for power bank, highly integrating switch charger, LED battery display cell and synchronous boost output, with charging current up to 2A and synchronous boost output up to 2.4A. It also provides discharge path management, battery display, torch, greatly simplifying peripheral circuits and components, and providing the simplest low-cost solution for power bank applications such as large-capacity lithium battery (lithium ion or lithium polymer).
MP5046 is available in a ESOP8 package.
Switch charger, 2A default charging current
90% discharging efficiency @2A
Switch frequency for charger: 1MHz
Charging in three phases: trickle current mode, constant current mode and constant voltage mode
Adaptive adapter for adjusting charging current
Adjustable charging current based on temperature (automatically decrease with the increase of temperature)
C/10 charge termination and automatic recharging
Preset 4.2V (MP5046)/4.35V (MP5047) floating charge voltage with ±1% accuracy
Integrated charging over-voltage and battery over-temperature protections
5.1V synchronous boost output
Switch frequency for discharger: 500KHz
94% discharging efficiency
Automatic load identification and automatic shutdown at light load
Original temperature management technology for boost
Over-current, short-circuit, over-voltage and over-temperature protections of discharging module
2 LEDs display to indicate the battery fuel gauge, charge/discharge and abnormality
Clicking KEY to start discharge and long press to turn on/off the torch
Charging-discharging path management, discharge first
Standby power mobile devices such as mobile phones, tablet PCs, GPS, and electric tools
